| Self-locking screen/octagonal | |||||
| Shell length | Proportion | Inch | View size (width * height) | Carton dimensions | GW/NW kg |
| Outer diameter64 shell length 132.4cm | 1:1 | 67” | 120*120cm | 144*14*12.5 | 5.2/3.1 |
| 64 157.4cm | 1:1 | 80” | 145*145cm | 169*13.5*12 | 6.2/4.6 |
| 64 162.4cm | 1:1 | 84” | 150*150cm | 174*14*12.5 | 6.0/4.5 |
| 64 172.4cm | 1:1 | 89” | 160*160cm | 184*13.5*12 | 0 |
| 64 184.4cm | 1:1 | 96” | 172*172cm | 197*14*12.5 | 7.0/5.3 |
| 64 192.4cm | 1:1 | 100” | 180*180cm | 204*14*12.5 | 7.5/5.6 |
| 64 212.4cm | 1:1 | 112” | 200*200cm | 225*14*12.5 | 8.2/6.2 |
| 64 215.4cm | 1:1 | 113” | 203*203cm | 227*14*12.5 | 0 |
| 64 225.4cm | 1:1 | 118” | 213*213cm | 240*14*12.5 | 8.9/6.8 |
| 64 255.4cm | 1:1 | 135” | 240**240cm | 267*14*12.5 | 12.3/9.8 |
| 64 259.4cm | 1:1 | 136” | 244*244cm | 268*14*12.5 | 0 |
| 76 315.4cm | 1:1 | 167” | 300*300cm | 327*15.5*13 | 17.9/14.3 |
| 64 157.4cm | 4:3 | 72” | 145*110cm | 170*14*12.5 | 5.2/3.1 |
| 64 172.4cm | 4:3 | 80” | 160*120cm | 185*13.5*12 | 0 |
| 64 184.4cm | 4:3 | 86” | 172*130cm | 197*14*12.5 | 7.1/5.2 |
| 64 212.4cm | 4:3 | 100” | 200*150cm | 225*14*12.5 | 7.5/6.5 |
| 64 254.4cm | 4:3 | 120” | 240*180cm | 267*14*12.5 | 10.3/8.0 |
| 76 315.4cm | 4:3 | 150” | 300*220cm | 327*15.5*13 | 16.8/13.9 |
| 64 172.4cm | 16:9 | 72” | 160*90cm | 184*13.5*12 | 6.8/4.9 |
| 64 184.4cm | 16:9 | 78” | 172*97cm | 197*13.5*12 | 0 |
| 64 192.4cm | 16:9 | 82” | 180*180cm | 210*14*12.5 | 7.2/5.3 |
| 64 212.4cm | 16:9 | 90” | 200*112cm | 225*14*12.5 | 7.3/6.1 |
| 64 233.4cm | 16:9 | 100” | 221*124cm | 245*14*12.5 | 8.4/6.2 |
| 64 254.4cm | 16:9 | 108” | 240*135cm | 267*14*12.5 | 9.5/3 |
| 64 280.4cm | 16:9 | 120” | 265*149cm | 292*14*12.5 | 11.1/8.8 |
| 76 315.4cm | 16:9 | 135” | 300*168cm | 327*15.5*13 | 14.3/11.4 |
| 76 345.4cm | 16:9 | 150” | 330*187cm | 370*15.5*13 | 19.2/15.8 |
| Self-locking screen/box shell | |||||
| Shell length/80 square shell | Proportion | Inch | View size (width * height) | Carton dimensions | GW/NW kg |
| 134.4cm | 1:1 | 67” | 120*120cm | 144*14*12.5 | 5.2/3.1 |
| 159.4cm | 1:1 | 80” | 145*145cm | 169*13.5*12 | 6.2/4.6 |
| 164.4cm | 1:1 | 84” | 150*150cm | 174*14*12.5 | 6.0/4.5 |
| 174.4cm | 1:1 | 89” | 160*160cm | 184*13.5*12 | 0 |
| 186.4cm | 1:1 | 96” | 172*172cm | 197*14*12.5 | 7.0/5.3 |
| 194.4cm | 1:1 | 100” | 180*180cm | 204*14*12.5 | 7.5/5.6 |
| 214.4cm | 1:1 | 112” | 200*200cm | 225*14*12.5 | 8.2/6.2 |
| 217.4cm | 1:1 | 113” | 203*203cm | 227*14*12.5 | 0 |
| 227.4cm | 1:1 | 118” | 213*213cm | 240*14*12.5 | 8.9/6.8 |
| 257.4cm | 1:1 | 135” | 240**240cm | 267*14*12.5 | 12.3/9.8 |
| 261.4cm | 1:1 | 136” | 244*244cm | 268*14*12.5 | 0 |
| 317.4cm | 1:1 | 167” | 300*300cm | 327*15.5*13 | 17.9/14.3 |
| 159.4cm | 4:3 | 72” | 145*110cm | 170*14*12.5 | 5.2/3.1 |
| 174.4cm | 4:3 | 80” | 160*120cm | 185*13.5*12 | 0 |
| 186.4cm | 4:3 | 86” | 172*130cm | 197*14*12.5 | 7.1/5.2 |
| 214.4cm | 4:3 | 100” | 200*150cm | 225*14*12.5 | 7.5/6.5 |
| 256.4cm | 4:3 | 120” | 240*180cm | 267*14*12.5 | 10.3/8.0 |
| 317.4cm | 4:3 | 150” | 300*220cm | 327*15.5*13 | 16.8/13.9 |
| 174.4cm | 16:9 | 72” | 160*90cm | 184*13.5*12 | 6.8/4.9 |
| 186.4cm | 16:9 | 78” | 172*97cm | 197*13.5*12 | 0 |
| 194.4cm | 16:9 | 82” | 180*180cm | 210*14*12.5 | 7.2/5.3 |
| 214.4cm | 16:9 | 90” | 200*112cm | 225*14*12.5 | 7.3/6.1 |
| 235.4cm | 16:9 | 100” | 221*124cm | 245*14*12.5 | 8.4/6.2 |
| 256.4cm | 16:9 | 108” | 240*135cm | 267*14*12.5 | 9.5/3 |
| 282.4cm | 16:9 | 120” | 265*149cm | 292*14*12.5 | 11.1/8.8 |
| 317.4cm | 16:9 | 135” | 300*168cm | 327*15.5*13 | 14.3/11.4 |
| 347.4cm | 16:9 | 150” | 330*187cm | 370*15.5*13 | 19.2/15.8 |
